AI Smart BSD Display 7-Inch Waterproof Real-Time Vehicle Blind Spot Alert

The YWX-729 B BSD multifunctional monitor is designed for heavy-duty vehicles, Addressing Blind Spot Challenges And Providing Comprehensive Visual Support. It Features A Multi-Language Interface, Remote Control, And Built-In Speakers For Clear Audio. This Monitor Can Manage Video And Audio Feeds From Four Cameras Simultaneously, With An Image Flipping Function For Versatile Viewing. Its Wide Voltage Design Ensures Reliable Performance In Various Conditions, Making It An Ideal Safety Solution For Heavy-Duty Vehicles.

Multiple Menu Languages Available: English, Arabic, Spanish, and Default English. Customization Available.
With Remote Control Function
Display With Built-In Speaker, Volume Adjustable
Supports Video Input From 4 Cameras At The Same Time
Support Ahd1080/720p Signal Camera
Recording And Playback Function
Support Four-Channel Single-Channel Line Control Triggering
With 9- 35V Wide Voltage Power Supply

Technical Specifications

Model	YWX-729B BSD
Screen Size	7″
Ratio	16:9
Resolution	1024（W）* R.G.B * 600(H)
TV System	PAL/NTSC
Brightness	600cd/㎡
Contrast	500:1
Viewing Angle	U/D:85°/85°,R/L:85°/85°
Image Settings	Dection Area, Identification, Brightness、Parking Monitoring
Video Format	AHD
Mirror Flip	Non-mirror, mirror
Video Channel	Four channel video input
Reversing Delayed	0-9s
Line Control Channel Trigger	Supports four single-channel triggers
Power Supply	9-35V，DC/<9W
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃

YWX-729 B AI Smart BSD Display

The AI Smart BSD display YWX-729 B is an advanced, multifunctional monitor designed specifically for heavy-duty vehicles. With a focus on blind spot detection (BSD) and real-time video monitoring, this intelligent display enhances vehicle safety and operational awareness. It features a multi-language interface, supports four cameras simultaneously, and includes built-in audio and remote functionality for ease of use.

Key Features

🌐 Multi-Language Interface

The AI Smart BSD display supports multiple menu languages, including English, Arabic, and Spanish, with English as the default. Custom language options are also available to suit international user requirements, making the operation clear and intuitive for all users.

🎮 Remote Control & Intuitive Operation

Equipped with a full-featured remote control, the YWX-729 B offers convenient navigation and configuration. Whether adjusting settings or switching camera views, users can control the AI Smart BSD display without reaching for physical buttons—ideal for drivers in motion.

🔊 Built-In Speaker with Adjustable Volume

The built-in speaker enhances the monitoring experience with clear audio output. Volume can be adjusted according to the environment, ensuring that alerts and audio from cameras are always heard. This AI Smart BSD display is more than just visual—it’s a complete sensory solution.

🎥 4-Camera Input with Real-Time Monitoring

Supporting simultaneous video input from up to four cameras, the monitor offers a comprehensive 360° view. Compatible with AHD1080/720P signal cameras, the AI Smart BSD display ensures high-definition visuals from every angle, making it perfect for trucks, buses, and industrial equipment.

📝 Recording, Playback & Triggering

Features include video recording, playback, and four-channel single-channel line control triggering. This allows drivers to review footage, document events, and respond instantly to vehicle movements or alarms. The AI Smart BSD display ensures full visual control at all times.

🔌 Wide Voltage Compatibility

Built with a 9–35V wide voltage power supply, the monitor is optimized for heavy-duty and commercial vehicles. Whether installed in construction equipment or large transport fleets, the AI Smart BSD display delivers consistent and reliable performance in varied voltage environments.

Applications

Heavy-duty vehicle blind spot monitoring
Fleet safety management
Commercial trucking
Construction and agricultural machinery

Why Choose the AI Smart BSD Display?

With its combination of smart features, durable design, and user-centric controls, the YWX-729 B AI Smart BSD display is a must-have for any commercial or heavy-duty vehicle. It reduces blind spot risks, enhances operational visibility, and provides a centralized hub for video and audio surveillance.
