700TVL HD Inside Cabin Camera For Bus Police Wagon & Other Indoor Application

YWX-004 700 Tvl Hd Inside Cabin Camera Is A Sight For Sore Eyes. With Excellent Sealing Performance And Easy Installation, Its Shell Opening Design Ensures That Heat Generated During Use Does Not Damage Internal Electronic Components By Quickly Dissipating It Out Of The Casing. The Multi-Layer High Transmittance Glass Lens Offers Crystal Clear Images Even In Low Light Conditions – Providing An Eloquently Detailed Nighttime Video Picture With Every Shot!

Support mirror switching
Support analog hd video 700TVL
Support ruler control functions

Technical Specifications

Image Sensor	1/3 CMOS 2083
TV System	NTSC/PAL
Effective Pixels	1920(H)×1080(V)
Sensing Area	4.880mmⅹ 3.670mm
Sync. System	Internal
Resolution	700TVL
Minimum Illumination	0.1 Lux (day), 0 Lux (with IR)
Microphone	Optional
IR LED Qty	12PCS
Video Output	1.0 Vp-p/75 Ohm
Scanning System	interlace
AGC	AUTO
Signal to noise ratio	Better than 48dB
White balance	AUTO
Gamma Consumption	0.45
Electronic Shutter	AUTO
Backlight Compensation	AUTO
Power Supply	DC12V
Lens	2.8mm
Lens Angle	115°
Current Drain	65±5mA
Operating Temperature	-20℃-70℃,RH 95% MAX

YWX-004 HD Inside Cabin Camera

The YWX-004 HD inside cabin camera is designed to deliver high-quality in-vehicle monitoring with superb clarity and reliability. Equipped with a 700TVL analog HD video output, mirror switching support, and ruler control functions, this compact yet powerful device is ideal for interior surveillance in commercial vehicles, buses, taxis, and rideshare fleets. Its advanced heat dissipation design and excellent sealing ensure durability even in demanding environments.

Key Features

🔄 Mirror Image Switching

The HD inside cabin camera supports mirror image switching, allowing users to adapt the viewing orientation according to different mounting positions. Whether mounted on the windshield or inside the cabin roof, the image can be flipped for optimal clarity and usability.

🎥 700TVL Analog HD Video

Delivering analog HD video with a resolution of 700TVL, the HD inside cabin camera ensures sharp, detailed footage that is ideal for in-vehicle safety monitoring. Whether it’s day or night, this camera captures the full story with impressive visual accuracy.

🧭 Ruler Control Function

The integrated ruler control function allows users to set visual guidelines on the screen for measurement reference or to assist with alignment, enhancing usability in various monitoring and security scenarios inside the vehicle.

🌡️ Heat Dissipation Design

The shell of the HD inside cabin camera features an intelligent open-structure design that allows quick heat release, preventing damage to internal components. This ensures stable, long-term operation even during extended use in high-temperature environments.

🔒 Superior Sealing & Easy Installation

Built with a focus on durability, this camera provides excellent sealing performance to protect against dust and humidity. The HD inside cabin camera is also simple to install, making it suitable for fleets and vehicle owners who need quick deployment without compromising performance.

🌙 High-Transmittance Glass Lens

The multi-layer high-transmittance lens delivers crystal-clear images, even under low-light conditions. The HD inside cabin camera provides a refined and detailed night video experience, enhancing cabin visibility during nighttime drives or stops.

Applications

Ride-hailing and taxi interior monitoring
Bus and shuttle safety systems
Fleet vehicle driver behavior recording
Commercial in-cabin surveillance

Why Choose the HD Inside Cabin Camera?

Whether for safety, compliance, or enhanced situational awareness, the YWX-004 HD inside cabin camera offers reliable, high-quality cabin video performance. With its combination of analog HD resolution, smart heat management, and adaptable image settings, the HD inside cabin camera is a trusted solution for secure and clear in-vehicle monitoring.
