7 Inch 4CH AI BSD Monitor with Recording Function

YWX-729 Multifunctional Monitor Is Designed For Heavy-Duty Vehicles, Addressing Blind Spot Challenges and Providing Comprehensive Visual Support. It Features A Multi-Language Interface, Remote Control, And Built-In Speakers For Clear Audio. This Monitor Can Manage Video And Audio Feeds From Four Cameras Simultaneously, With An Image Flipping Function For Versatile Viewing. Its Wide Voltage Design Ensures Reliable Performance In Various Conditions, Making It An Ideal Safety Solution For Heavy-Duty Vehicles.

Multiple Menu Languages Available: English, Arabic, Spanish, and Default English. Customization Available.
With Remote Control Function
Display With Built-In Speaker, Volume Adjustable
Supports Video Input From 4 Cameras At The Same Time
Support AHD1080/720p Signal Camera
Recording and Playback Function
Support Four-Channel Single-Channel Line Control Triggering
With 9- 35V Wide Voltage Power Supply

Technical Specifications

Model	YWX-729 BSD
Screen Size	7″
Ratio	16:9
Resolution	1024（W）* R.G.B * 600(H)
TV System	PAL/NTSC
Brightness	600cd/㎡
Contrast	500:1
Viewing Angle	U/D:85°/85°,R/L:85°/85°
Image Settings	Dection Area, Identification, Brightness、Parking Monitoring
Video Format	AHD
Mirror Flip	Non-mirror, mirror
Video Channel	Four channel video input
Reversing Delayed	0-9s
Line Control Channel Trigger	Supports four single-channel triggers
Power Supply	9-35V，DC/<9W
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃

YWX-729 AI BSD Monitor

The YWX-729 AI BSD monitor is a robust, multifunctional display system built specifically for heavy-duty vehicles. Designed to enhance driver visibility and reduce blind spot risks, it offers reliable video input support from four cameras and integrates audio feedback, real-time monitoring, and playback. With its durable design and flexible voltage compatibility, the AI BSD monitor is an ideal safety solution for trucks, buses, and industrial equipment.

Key Features

🌐 Multi-Language OSD Menu

The AI BSD monitor comes with menu language support in English, Arabic, and Spanish, with English set as the default. Customized language options are available, ensuring intuitive operation in diverse global markets.

🎮 Remote Control Functionality

Equipped with a responsive remote control, the YWX-729 AI BSD monitor allows users to navigate settings, switch views, and control playback with ease, making it especially convenient in moving vehicles.

🔊 Built-in Speaker with Adjustable Volume

The display includes a built-in speaker that provides clear, real-time audio alerts. Volume levels can be easily adjusted to fit different environments, enhancing driver awareness in both quiet and noisy conditions.

🎥 Four-Camera Video Input

Supporting up to four simultaneous AHD1080/720P camera inputs, the AI BSD monitor offers a comprehensive view of the surroundings. This capability is ideal for eliminating blind spots and enhancing driving safety in large vehicles and complex environments.

📝 Recording, Playback, and Triggering

This monitor features recording and playback functionality, along with four-channel single-channel line control triggering. Drivers can monitor and review footage efficiently, providing valuable insights and supporting operational safety.

🔌 Wide Voltage Power Supply (9–35V)

Built for reliability, the AI BSD monitor supports a 9–35V wide voltage range, making it suitable for various vehicle types, including those with fluctuating power systems.

Applications

Long-haul trucks and commercial transport
Agricultural and construction vehicles
Fleet and logistics vehicle management
Blind spot assistance and reverse monitoring

Why Choose the AI BSD Monitor?

The YWX-729 AI BSD monitor delivers professional-grade functionality in a compact, easy-to-use package. It supports multiple cameras, offers flexible controls, and ensures high-definition visuals and audio—all while adapting to demanding operational environments. With its smart features and safety-focused design, the AI BSD monitor is the perfect fit for drivers who require full situational awareness on the road.
