1080P AHD Car Camera

YWX-009 Reversing Camera Has Night Vision Function, Which Means It Can Clearly Show The Real Colors And Pictures No Matter Day Or Night. It Can Greatly Improve The Safety Of Night Driving And Provide Users With A Clear Vision. This Camera Has The Highest IP69k Waterproof Rate, So When It Rains Or Car Washed, It Will Not Get Water And Work As Usual. Also, We Will Do A Long-Term High-Pressure Soaking To Ensure The Quality Before Shipping.

IP69K
1.3 megapixel sensor
Support mirror switching
With full color function

Technical Specifications

Image Sensor	1/3 CMOS 2083
TV System	NTSC/PAL
Effective Pixels	1920(H)*1080(V)
Sensing Area	4.880mmⅹ 3.670mm
Sync. System	Internal
Resolution	1080P/720P
Minimum Illumination	0.1 Lux (day), 0 Lux (with IR)
Microphone	Optional
Video Output	1.0 Vp-p/75 Ohm
Scanning System	interlace
Material	Alluminum alloy
Signal to noise ratio	Better than 48dB
White balance	AUTO
Gamma Consumption	0.45
Electronic Shutter	AUTO
Backlight Compensation	AUTO
Power Supply	DC12V
Lens	2.8mm
Lens Angle	125°
Current Drain	65±5mA
Operating Temperature	-20℃-70℃,RH 95% MAX
Storage Temperature	-30℃-80℃,RH 95% MAX

YWX-009 1080P AHD Car Camera

The YWX-009 1080P AHD car camera is a high-performance vehicle camera designed to enhance driving safety, especially during reversing and low-light conditions. Equipped with night vision, a full-color imaging sensor, and IP69K waterproof protection, this camera ensures reliable performance in all environments. Its compact design and advanced features make it ideal for cars, trucks, buses, and other commercial vehicles.

Key Features

📸 High-Resolution 1.3MP Sensor

The 1080P AHD car camera features a 1.3-megapixel sensor that delivers crystal-clear, high-definition visuals. Whether you’re parking in tight spots or navigating difficult roads, the sharp image quality provides superior visibility and better decision-making.

🌈 Full Color Function

Unlike traditional black-and-white night vision, the YWX-009 offers full-color video even in low-light conditions. The 1080P AHD car camera ensures realistic and vibrant image reproduction, giving drivers accurate visual information regardless of time or lighting.

🔄 Mirror Image Switching

The camera supports mirror switching, allowing it to be used as a front or rear view camera depending on your installation needs. This feature makes the 1080P AHD car camera flexible and compatible with various vehicle types.

💧 IP69K Waterproof Rating

Built to withstand the toughest environments, the YWX-009 boasts an IP69K waterproof rating—the highest level of protection available. Whether exposed to heavy rain, high-pressure washing, or muddy terrain, the 1080P AHD car camera maintains stable operation without compromise.

🌙 Night Vision Clarity

Designed for both day and night use, the 1080P AHD car camera offers excellent night vision capabilities. It ensures that drivers have a clear, colored view even in complete darkness, significantly enhancing safety during night-time driving or parking.

🛠️ Rigorous Quality Testing

Before shipment, each unit undergoes long-term high-pressure soaking and waterproof testing to ensure durability and consistent performance. The 1080P AHD car camera is built to last, delivering peace of mind with every use.

Applications

Reversing and parking assistance
Commercial fleet vehicles
Off-road and construction vehicles
Public transportation safety systems

Why Choose the 1080P AHD Car Camera?

Combining durability, high-definition imaging, and all-weather performance, the YWX-009 1080P AHD car camera is the ideal solution for drivers looking to enhance vehicle safety. Its full-color night vision, waterproof design, and flexible installation options make it suitable for a wide range of vehicle types and driving conditions.
