YWX-1019 10.1″ Multi-Function LCD Monitor—A Compact Powerhouse Designed For Versatility And Value. Direct From The Manufacturer, This Monitor Delivers Crisp 1024×600 Resolution, 400 Cd/M² Brightness, And Multi-Input Compatibility (HDMI/VGA/AV/USB/BNC) For Gaming, Retro Tech, Cctv Surveillance and Even In-Vehicle Use. With Built-In Speakers, Dual Mounting Options and A Car-Ready Power Adapter, It’S The Ultimate All-In-One Display For Home, Office, Or On-The-Go Projects At An Unbeatable Price.

Supports HDMI, VGA ,AV and BNC Ports.
With 9-35v Wide Voltage Of Power Supply
Supports For Cctv Surveillance

Technical Specifications

Model	YWX-1019
Screen Size	10″
Ratio	16:9
Resolution	1024（W）* R.G.B * 600(H)
TV System	PAL/NTSC/AUTO
Brightness	500cd/㎡
Contrast	500:1
Active Area	154.08(W) × 85.92(H) mm
Viewing Angle	U/D:85°/85°,R/L:85°/85°
Image Settings	Brightness、Color、Contrast
Video Format	CVBS
Reverse Function	Single way back (ruler setting function)
Reversing Delayed	0-15s
Power Supply	9-35V，DC/<9W
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃
